Allen-Bradley 825-P User Manual

250 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter E DeviceNet Information
Standard Output
(Consumed) Assemblies
Instance 2 is the required output (consumed) assembly defined in the Motor
Overload Profile.
Instance 150 is the standard output (consumed) assembly with Network Inputs.
Instance 151 is the standard output (consumed) assembly with Network Inputs.
This is a “Read/Write” control assembly.
Instance 3 ODVA Overload
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Flt Reset
Instance 150 Standard Consumed Starter
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Aux 8 Aux 7 Aux 6 Aux 5 Aux 4 Aux 3 Aux 2 Aux 1
1Flt Reset Aux 10 Aux 9
Instance 151 Standard Consumed Starter with Network Inputs
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Aux 8 Aux 7 Aux 6 Aux 5 Aux 4 Aux 3 Aux 2 Aux 1
1Flt Reset Aux 10 Aux 9
2 Net In 8 Net In 7 Net In 6 Net In 5 Net In 4 Net In 3 Net In 2 Net In 1
3 Net In 16 Net In 15 Net In 14 Net In 13 Net In 12 Net In 11 Net In 10 Net In 9
4 Net In 24 Net In 23 Net In 22 Net In 21 Net In 20 Net In 19 Net In 18 Net In 17
5 Net In 32 Net In 31 Net In 30 Net In 29 Net In 28 Net In 27 Net In 26 Net In 25
Instance 181 Hardware Outputs 1-6
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Aux 8 Aux 7 Aux 6 Aux 5 Aux 4 Aux 3 Aux 2 Aux 1
1Flt Reset Aux 10 Aux 9
