Allen-Bradley 825-P User Manual

Rockwell Automation Publication 825-UM004D-EN-P - November 2012 45
Chapter 4
Hardware Commissioning
All hardware that is added to the 825-P must be installed and commissioned
individually. Listed below are the processes required to commission an 825-P
for a specific Converter Module, Optional I/O Module, Optional Voltage
Module, and Optional Communication Module.
Connecting a Converter
Module (MCM)
• Connect the MCM module to 825-P
• Apply power to the 825-P base relay
• The following fault will be displayed:
• Navigate to Main > Status to view the Status display
• The display will show the following message:
• Press the Enter key to confirm that you want this hardware change
STATUS FAIL
MCM/CWE Error
Confirm Hardware
Config (Enter)
Confirm Config?
Yes
No
