Allen-Bradley 825-P User Manual

262 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter E DeviceNet Information
Overload Object - CLASS
CODE 0x002c
No class attributes are supported for the Overload Object. Only Instance 1 of
the Overload Object is supported.
The following common services are implemented for the Overload Object:
DeviceNet Interface Object
- CLASS CODE 0x00B4
The following class attributes are supported for the DeviceNet Interface Object:
Only Instance 1 of the DeviceNet Interface Object is supported:
Service Code
Implemented for:
Service Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
5 Get Average Current UINT xxx.x amps
6 Get %Phase Imbal USINT xxx% FLA
7 Get % Thermal Utilized USINT xxx% FLA
8 Get Current L1 UINT xxx.x amps
9 Get Current L2 UINT xxx.x amps
10 Get Current L3 UINT xxx.x amps
11 Get Ground Current UINT xxx.x amps
Service Code
Implemented for:
Service Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No No Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 02
