Allen-Bradley 825-P User Manual

Rockwell Automation Publication 825-UM004D-EN-P - November 2012 47
Hardware Commissioning Chapter 4
• Press the Enter key to confirm that you want this hardware change
• Select Yes to confirm the new hardware configuration, and the display
will show:
• Press Enter to Reboot the relay
Adding an Optional I/O Card
• Remove control power from the relay, and remove the back cover
• Add the optional I/O card into Slot D in the 825-P
• Replace the cover and reapply control power to the relay
• The 825-P will detect a hardware configuration change and display the
foll
owing message:
• Navigate to Main > Status to view the Status display
• The display will show the following message:
• Press the Enter key to confirm that you want this hardware change
Confirm Config?
Yes No
Config Accepted
Enter to Reboot
STATUS Fail
I/O Card Failure
Confirm Hardware
Config (Enter)
Confirm Config?
Yes
No
