825-PDN DeviceNet Communication Card Chapter 9
Parameter Groups
The 825-PDN Device Communication Card contains five parameter groups.
The parameters shown in the DeviceLogix Parameters, DeviceNet Parameters,
Aux. Output Parameters, Misc. Parameter, and Status Parameters are discussed
in this section.
A complete list of all DeviceNet parameters is described in Appendix B.
Status Parameters DeviceNet
Parameters
Aux. Output
Parameters
Misc. Parameters DeviceLogix
Parameters
Hdw Inputs Autobaud Enable GrpA Pr FltState Set To Defaults Net Inputs 1
Hdw Outputs Consumed IO Assy GrpA Pr FltValue Net Inputs 2
Trip Status 1 Produced IO Assy GrpA DN FltState Net Outputs
Trip Status 2 Prod Assy Word 0 GrpA DN FltValue Network Override
Warn Status 1 Prod Assy Word 1 GrpA DN IdlState Comm Override
Warn Status 2 Prod Assy Word 1 GrpA DN IdlValue Net Out COS Mask
DNet Status Prod Assy Word 3 GrpB Pr FltState
Prod Assy Word 4 GrpB Pr FltValue
Prod Assy Word 5 GrpB DN FltState
Prod Assy Word 6 GrpB DN FltValue
Prod Assy Word 7 GrpB DN IdlState
Consumed IO Size GrpB DN IdlValue
Produced IO Size GrpC Pr FltState
Status COS Mask 1 GrpC Pr FltValue
Status COS Mask 2 GrpC DN FltState
Trip COS Mask 1 GrpC DN FltValue
Trip COS Mask 2 GrpC DN IdlState
Warning COS Mask 1 GrpC DN IdlValue
Warning COS Mask 2
DNet Voltage
