Chapter E DeviceNet Information
The following instance attributes are implemented for all parameter attributes:
Parameter Object - CLASS
CODE 0x0010
The following class attributes are supported for the Parameter Object:
The 825-PDN DeviceNet Communication Card serves modules serves up the
following instances of the parameter group object:
• Instance 1 = Status Parameters
• Instance 2 = DeviceNet Parameters
• Instance 3 = User I/O Parameters
Attribute ID Access Rule Name Data Type Value
1 Get/Set Value Specified in Descriptor
2 Get Link Path Size USINT
3 Get Link Path Array of:
BYTE
EPATH
4 Get Descriptor WORD
5GetData TypeEPATH
6 Get Data Size USINT
7 Get Parameter Name String SHORT_STRING
8 Get Units String SHORT_STRING
9 Get Help String SHORT_STRING
10 Get Minimum Value Specified in Descriptor
11 Get Maximum Value Specified in Descriptor
12 Get Default Value Specified in Descriptor
13 Get Scaling Multiplier UINT
14 Get Scaling Divisor UINT
15 Get Scaling Base UINT
16 Get Scaling Offset INT
17 Get Multiplier Link UINT
18 Get Divisor Link UINT
19 Get Base Link UINT
20 Get Offset Link UINT
21 Get Decimal Precision USINT
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT
2GetMax InstanceUINT
