DeviceNet Information Chapter E
Identity Object - CLASS
CODE 0x0001
The following class attributes are supported for the Identity Object:
The table below shows Instance 1 attributes of the Identity Object. Each instance
of the Identity Object contains the following attributes:
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
Attribute ID Access Rule Name Data Type Value
1 Get Vendor UINT 1
2 Get Device Type UINT 3
3 Get Produce Code UINT 100 (64 hex)
4 Get Revision
Major Revision
Minor Revision
Structure of
UINT
UINT
0RRRMMMM
0 = reserved by
DeviceNet
RRR = Revision of Motor
Relay
MMMM = Revision of
DNet card
5 Get Status WORD Bit 0 - 0=not owned;
1=owned by master
Bit 2 - 0=Factory
Defaulted; 1=Configured
Bit 8 - Minor
Recoverable fault
Bit 9 - Minor
Unrecoverable fault
Bit 10 - Major
Recoverable fault
Bit 11 - Major
Unrecoverable fault
6 Get Serial Number UDINT Unique number for each
device
7* Get Produce Name
String Name
ASCII String
Structure of
USINT
STRING
825-P
9 Get Configuration
Consistency Value
UINT Unique value depending
on output of the
parameter checksum
algorithm.
