Rockwell Automation Publication 825-UM004D-EN-P - November 2012 95

Configuring Protection & Logic Functions Chapter 6

I/O Assignments

Trip Relay I/O

Table 42 - Trip Relay Assignments

Setting Prompt 01234567Description

TRIP A X Overload

X Undercurrent

X Jam

X Current Imbalance

X Short Circuit

X RTD (Winding/Bearing)

X PTC

X Ground Fault (Residual)

TRIP B X VAR

X Underpower

X Undervoltage

X Overvoltage

X Phase Reversal

X Power Factor

X Speed Switch

X Ground Fault (Core Balance)

TRIP C X Start Time

X Frequency 1

X Frequency 2

X RTD (Other)

X RTD (Ambient)

X PTC Error

X RTD Error

X MCM Error

TRIP D X Comm Idle

X Comm Loss

X Remote Trip

X Comm Fault

X Reserved

NOTE: The 825-P uses settings TRIPA through TRIPD and setting TRIP FAIL-SAFE (see Table 38)

to determine the operation of the Trip Output.
