Removing
•
Place the engine support so as to fa-
cilitate oil pump removal operations.
•
Undo and remove the two screws fixing
the oil pump.
•
Remove the oil pump and the O-ring
underneath; collect the oil pipes and
their guides.
Inspection
•
Male sure the delivery (1) and intake
(2) pipes do not leak or have pores at
their connecting points. Replace if re-
quired.
•
Clean the oil reservoir, the oil reservoir
filter and the oil intake pipe.
•
Always replace the oil pump when
damaged or leaking.
•
After installing the flexible pipe of the
oil pump, adjust it so that when in idle
position the marks on the pump lever
(3) are aligned with the pump (4) seat.
BLEEDING
Purge the oil pump and its pipes:
Engine RX SX 125
ENG - 126
