Cooling system
Level check
Check and top-up
CAUTION
WAIT FOR THE ENGINE TO COOL DOWN BEFORE CHECKING OR TOPPING-UP THE COOLANT
LEVEL.
•
Shut off the engine and wait until it
cools off.
•
Park the vehicle on firm and level
ground.
•
Keep the vehicle upright with the two
wheels on the ground.
•
Turn the radiator cap (1) anticlockwise
just one click.
•
Wait a few seconds so that possible
pressure in the circuit may be purged.
•
Turn the radiator cap (1) anticlockwise
again and remove it.
•
Make sure the fluid covers the radiator
plates completely.
CAUTION
DO NOT ADD ADDITIVES OR OTHER SUBSTANCES TO
THE FLUID.
WHEN USING A FUNNEL OR ANY OTHER ELEMENT,
MAKE SURE IT IS PERFECTLY CLEAN.
CAUTION
COOLANT IS TOXIC IF INGESTED; CONTACT WITH EYES
OR SKIN MAY CAUSE IRRITATION. DO NOT INTRODUCE
YOUR FINGERS OR ANY OTHER OBJECT TO CHECK IF
THERE IS COOLANT OR NOT.
Braking system
RX SX 125 Maintenance
MAIN - 29
