APRILIA SX 125 User Manual

Seat
•
Place the vehicle on the service stand.
•
Insert the key in the lock.
•
Turn the key anticlockwise.
•
Lift and remove the saddle.
UPON REFITTING:
BEFORE LOWERING AND LOCKING THE SADDLE,
CHECK THAT THE KEY HAS NOT BEEN LEFT INSIDE THE
GLOVE-BOX / TOOLKIT COMPARTMENT.
•
Fit the saddle making sure to position
the corresponding rear hooks correct-
ly.
•
Lower and press the saddle to trip the
lock.
BEFORE RIDING, MAKE SURE THAT THE SADDLE IS
CORRECTLY LOCKED INTO POSITION.
Headlight assy.
•
Undo and remove both screws on the
upper plate.
•
Undo and remove the two screws fas-
tening the mudguard and collect the
nuts and washers from the bottom.
Bodywork RX SX 125
BODYW - 200

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
