TURN INDICATORS
•
If necessary, remove the turn indica-
tors working from any side, then undo
and remove the screw and carefully
slide off the gauge with cables.
LICENSE PLATE LIGHT
•
If necessary, remove the license plate
light, undo and take out the screw and
carefully slide off the light with cables.
REAR LIGHT
•
If necessary remove the rear light, un-
do and take out both screws and collect
the washers.
•
Slide off the rear light with cables care-
fully.
Side body panels
CENTRAL FAIRING
The following operations refer to only one fair-
ing but are valid for both.
•
Unscrew and remove the screw and
collect the collar.
Bodywork RX SX 125
BODYW - 202

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
