Name Torque in Nm
Lower plate retainer - M6x30 (4) 10 Nm (7.37 lbf ft)
Foot lock on wheel pin - M6x25 (2) 10 Nm (7.37 lbf ft)
Bearing pack ring nut preloading (1) 17 Nm (12.54 lbf ft)
Bearings pack ring nut (1) 7 Nm (5.16 lbf ft)
Fork cap (1) 80 Nm (59 lbf ft)
REAR SUSPENSION
Name Torque in Nm
Shock absorber upper retainer - TCEI M10x55 screw (1) 50 Nm (36.9 lbf ft)
Single connecting rod to chassis attachment retainer - TCEI
M12x107 screw (1)
85 Nm (62.7 lbf ft)
Double connecting rod to single connecting rod retainer - TE
M10x61 screw (3)
50 Nm (36.9 lbf ft)
ENGINE
Name Torque in Nm
Engine upper plate to engine retainer - TCEI M8x80 screw (1) 25 Nm (18.44 lbf ft)
Gear shift lever retainer - TCEI M6x20 screw (1) 10 Nm (7.37 lbf ft)
Engine front retainer - TCEI M10x130 screw (1) 50 Nm (36.88 lbf ft)
Engine rear retainer - TCEI M8x60 screw (1) 25 Nm (18.44 lbf ft)
Pinion protection case retainer - TCEI M8x60 screw (2) 25 Nm (18.44 lbf ft)
Solenoid retainer - TE M6x30 screw (1) 10 Nm (7.37 lbf ft)
Coil to chassis retainer - TE M6x40 screw (2) 10 Nm (7.37 lbf ft)
FILTER CASING
Name
Torque in Nm
Filter half-housing retainer (7) 3 Nm (2.2 lbf ft)
Filter cover retainer (4) 3 Nm (2.2 lbf ft)
Filter housing to saddle pillar upper retainer (1) 6 Nm (4.42 lbf ft)
Filter casing / mudflap to saddle pillar lower retainer (2) 6 Nm (4.42 lbf ft)
SAS valve to chassis / horn retainer - TE M6x12 screw (2) 10 Nm (7.37 lbf ft)
EXHAUST SYSTEM
Name
Torque in Nm
Muffler retainer - TE M6x16 screw (1) 10 Nm (7.37 lbf ft)
Intermediate pipe retainer - TE M6x12 screw (1) 10 Nm (7.37 lbf ft)
Protection retainer - TE M6x12 screw (2) 10 Nm (7.37 lbf ft)
Silencer support bracket retainer - TE M6x16 screw (2) 10 Nm (7.37 lbf ft)
Silencer retainer - TCEI M6x16 screw (1) 10 Nm (7.37 lbf ft)
Silencer support retainer - TE M6x16 screw (2) 10 Nm (7.37 lbf ft)
COOLING SYSTEM
Name
Torque in Nm
Radiator to chassis retainer - TE M6x25 screw (6) 10 Nm (7.37 lbf ft)
FRONT WHEEL
Name
Torque in Nm
Wheel pin retainer (1) 80 Nm (59 lbf ft)
Brake disc retainer - TSPEI M8x16 screw (6) 25 Nm (18.44 lbf ft) - Loctite 243
REAR WHEEL
Name
Torque in Nm
Rear wheel pin retainer - M16x1.5 nut (1) 100 Nm (73.75 lbf ft)
Brake disc retainer - TSPEI M6x16 screw (6) 10 Nm (7.37 lbf ft) - Loctite 243
Crown retainer - TSPEI M8x26 screw (6) 25 Nm (18.44 lbf ft) - Loctite 243
Speed sensor support plate retainer - TE M6x12 screw (2) 10 Nm (7.37 lbf ft)
Speed sensor retainer - TE M6x16 screw (1) 10 Nm (7.37 lbf ft)
RX SX 125 Characteristics
CHAR - 15
