APRILIA SX 125 User Manual

•
Operating from both sides, undo and
remove the chassis fixing screw and
collect the nut.
CAUTION
ONCE THE CHASSIS IS RELEASED PAY ATTENTION TO
THE REAR SIDE OF THE MOTORCYCLE AND PLACE IT ON
THE GROUND LOWERING THE HOIST.
•
Slide the filter casing upwards.
Fuel tank
TANK COVER
•
Remove the saddle.
•
Undo and remove the two screws.
•
Undo and remove the front screw.
•
Disconnect the fuel vapour recovery
pipe.
•
Unscrew and remove the fuel tank cap.
•
Remove the fuel tank cover and screw the cap again.
See also
Bodywork RX SX 125
BODYW - 208

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
