Tighten the bleed screw again and fill
the reservoir until the oil reaches the
recommended level.
Battery
BATTERY REMOVAL
•
Remove the saddle.
•
Make sure the ignition switch is set to
«OFF».
•
Disconnect the negative ( -) lead first
and then the positive (red) (+) one.
•
Remove the battery breather pipe.
•
Remove the battery from its housing
and put it away on a level surface in a
cool and dry place.
CAUTION
ONCE REMOVED, THE BATTERY MUST BE PUT AWAY IN
A SAFE PLACE OUT OF THE REACH OF CHILDREN.
Tail guard
•
Remove the saddle and the central
side fairings.
•
Undo and remove the two screws.
•
Undo and remove the two lower
screws.
Bodywork RX SX 125
BODYW - 212

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
