Undo and remove the lower screw,
paying attention to the rear brake lever
placed on the right-hand side.
Upon refitting, replace clamps with the same type
and size of clamps.
See also
Seat
Fuel tank
Air box
•
Support the vehicle with a suitable under-sump stand.
•
Support the scooter rearcarriage with a hoist and suitable belts.
•
Remove the saddle.
•
Remove both central fairings.
•
Remove the six chassis side cover
clamps and loosen the lower screws to
rotate the cover rightwards.
•
Working from the right side, undo and
remove the screw and collect the collar
and the rubber ring.
RX SX 125 Bodywork
BODYW - 205

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
