APRILIA SX 125 User Manual

•
Remove the water pump with the help
of a square screwdriver.
REFITTING
•
Upon refitting follow the removal steps but in reverse order, paying special attention to the
alignment of the water pump control wheel, which must be aligned with the reference on the
crankcase when refitting.
Removing the radiator
•
Remove both front side fairings.
•
Place a container of suitable capacity
underneath the sleeve.
•
Release the clamp.
•
Slide off the sleeve.
•
Empty the liquid into the container.
•
Open the radiator cap to facilitate
drainage.
Cooling system RX SX 125
COOL SYS - 196

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
