APRILIA SX 125 User Manual

•
Undo and remove the fixing screw.
The following operations refer to only one fair-
ing, but are valid for both.
•
Undo and remove the radiator fixing
screw.
•
Remove the front side fairing.
CHASSIS COVER
•
They are placed in the central area on
both sides of the vehicle. For regular
operations remove the three clamps
and turn the cover according to visibil-
ity requirements, acting on the lower
screw slightly loose.
If necessary, remove them from the vehicle:
•
Remove the three retaining clamps.
Bodywork RX SX 125
BODYW - 204

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
