8. Dust guard with clip
9. Spacer
10.Nut
11.Spring guide
12.Snap ring
13.Right pumping member rod
14.Right pumping member
15.Pin
16.Spring
17.Cap
18.Ring
19.Spring
20.Piston ring
21.Piston
22.Nut
23.Valve
24.Sliding bushing
25.Left pumping member rod
26.Left pumping member
27.Cap
28.Left piston
29.Nut
30.Right pumping member assembly
31.Left pumping member assembly
32.TE flanged screw
33.Stem + right wheel holder
34.Stem + left wheel holder
35.Spring
36.Preloading pipe
37.Sealing washer
38.TCE screw
39.Thickness
40.Thickness
41.Thickness
Removing the fork legs
CAUTION
POSITION THE OPTIONAL FRONT SERVICE STAND HIGH
CAUTION
Suspensions RX SX 125
SUSP - 146

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
