12.D11x6.6x1 green clic clamp
13.D28x8.6 clic clamp
14.D23.5x8 clic clamp
15.D23.5x8 clic clamp
16.D10.1 clamp
17.5x9 pipe
18.TE flanged screw M6x25
Coolant replacement
CAUTION
DO NOT USE YOUR VEHICLE IF THE COOLANT IS BELOW THE MINIMUM LEVEL.
CHECK THE COOLANT LEVEL PERIODICALLY OR AFTER LONG TRIPS.
•
Remove both front side fairings.
•
Place a container of suitable capacity
underneath the sleeve.
•
Release the clamp.
•
Slide off the sleeve.
•
Empty the liquid into the container.
•
Open the radiator cap to facilitate
drainage.
•
Unscrew and remove the drainage
plug (1) indicated by the mark OUT.
•
Unscrew and remove the radiator plug
to facilitate draining the coolant.
CAUTION
DO NOT DISPOSE OF THE FLUID INTO THE ENVIRON-
MENT.
•
Wait for the coolant to drain off and tighten the screw.
Cooling system RX SX 125
COOL SYS - 194
