7. Rear light
8. Right rear turn indicator
9. Speed sensor
10.STARTER MOTOR
11.Neutral sensor
12.Pick-up sensor
13.Intake air valve (MAJ2)
14.Spark plug
15.Left front turn indicator
16.Mixer oil level sensor
17.CDI control unit
18.Coolant temperature thermistor
19.Instrument panel
20.Front right turn indicator
21.Air temperature sensor
22.RAVE (Full Power) control solenoid
23.Horn
24.Throttle valve position sensor
25.Rear right turn indicator
Electrical system installation
INTRODUCTION
Scope and applicability
The purpose of this document is to define cables laying, their fastening on the motorcycle and possible
criticalities, special checks on connections and layouts, all this with the aim of obtaining vehicle relia-
bility.
Materials used and corresponding quantities
The electrical system consists of the following cable harnesses and parts:
•
1 Main Cable Harness
•
1 Front Tail Light Cable Harness
•
1 Ground lead
•
1 Cap for Magura Switches
•
1 Safety Diode
•
10 178x4 Large black clamps
•
3 98x2.5 Small black clamps
•
3 Rubber clamps
Special checks for the correct connection and laying of cables
This is the list of connectors the operator in charge of fitting must check they are correctly connected:
RX SX 125 Electrical system
ELE SYS - 39

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
