APRILIA SX 125 User Manual

Voltage regulator check
•
Output voltage 13.5 V - 15 V
•
Output current higher than 10 A (with
load)
Turn signals system check
Turn indicator device check
Check placing the tester probes on the poles:
+ / - 5.8 kOhm.
- / L (bulb) 5.3 kOhm.
- / L (bulb) 4.8 kOhm.
•
Undo and remove the screw and re-
move the protection glass with caution
so as not to break the fitting tooth.
•
Slightly press the bulb and turn it anti-
clockwise.Take out the bulb from its
fitting.
•
Upon replacement, insert a bulb of
equal rating in the bulb holder, making
the two guiding pins coincide with their
guides on the bulb holder.
RX SX 125 Electrical system
ELE SYS - 59

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
