APRILIA SX 125 User Manual

•
press the MODE button and insert the key again
•
press and hold the MODE button until the letters WS are shown on the LCD on the right-
hand bottom side (5 sec)
•
always holding down the MODE button, operate the high-beam lights to flash 5 times
•
release the MODE button and 0001 or 0002 is displayed
•
press the MODE button again to change from 0001 (SX 125 17 wheel) to 0002 (RX 125 18
wheel) and vice versa. Hold down the MODE button to confirm and WS will be displayed
•
release the MODE button, then set the key to OFF
Resetting the odometer
The odometer can be reset only once and within 200 km (124.27 mi)
•
remove the key
•
press the MODE button and insert the key again
•
press and hold the MODE button until the letters WS are shown on the LCD on the right-
hand bottom side (5 sec)
•
always holding down the MODE button, operate the high-beam lights to flash 10 times +
turn indicators to flash 5 times
Service warning light reset
The service warning light is reset as follows :
•
hold down the MODE button when in-
serting the key until WS is displayed in
the lower right hand side angle (when
the MODE button is released, the word
END is displayed).
Electrical system RX SX 125
ELE SYS - 54

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
