2. Silencer
3. Silencer clamp
4. Muffler protection
5. Silent-block
6. M6 Flanged self-locking nut
7. Insulating washer
8. Clip M6
9. TE flanged screw M6x16
10.Traction cyl. helical spring
11.TCEI M6x16 screw
12.Silencer plate
13.M6x12 TE flanged screw
14.6.4X11X0.5 spring washer
15.6.6x18x1.6 washer
16.Insulating washer
17.Central exhaust pipe
18.Silencer gasket
19.Lower self locking nut
20.Pull screw
21.Plate
22.Washer
Removing the tail pipe
•
Rotating it on the screw, move the fair-
ing that covers the chassis.
•
Undo and remove the front fixing screw
of the silencer pipe and collect the
washer.
Chassis RX SX 125
CHAS - 184

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
