APRILIA SX 125 User Manual

CHECK THE CLUTCH CONTROL CABLE IS IN GOOD CON-
DITIONS: THERE SHOULD BE NO SIGNS OF CRUSHING
OR WEAR ALL ALONG THE SHEATH.
•
Lubricate the clutch wire frequently with an appropriate grease to avoid early wear and cor-
rosion.
See also
Side fairings
Headlight adjustment
NOTE
IN COMPLIANCE WITH LOCAL REGULATIONS IN FORCE, SPECIFIC PROCEDURES MUST BE
FOLLOWED WHEN CHECKING LIGHT BEAM ADJUSTMENT.
For a quick check of the correct adjustment of the
front light beam:
•
Place the vehicle 10 m (32.81 ft) away
from a vertical wall and make sure the
ground is level.
•
Turn on the low-beam light, sit on the
vehicle and check that the light beam
projected to the wall is a little below the
headlight horizontal straight line (about
9/10 of the total height).
To adjust the light beam:
•
Operating on both sides, undo the
screw.
•
Adjust the headlamp until the desired
position is obtained.
•
Working from both sides, tighten the
screw. After adjusting:
NOTE
CHECK THAT THE LIGHT BEAM VERTICAL DIRECTION IS
CORRECT.
RX SX 125 Maintenance
MAIN - 33

APRILIA SX 125 Specifications

General

Displacement	124.2 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Transmission	6-speed
Rear Suspension	Monoshock
Front Tire	100/80-17
Rear Tire	130/70-17
Compression Ratio	12.5:1
Starter	Electric
Clutch	Wet multi-plate
Front Brake Disc	300 mm
Rear Brake Disc	220 mm
Dry Weight	134 kg
Bore x Stroke	58 mm x 47 mm
Max Power	11 kW (15 HP) @ 10, 000 rpm
Front Suspension	41 mm USD fork
Front Brake	Single 300 mm disc
Rear Brake	Single disc
Fuel Tank Capacity	7 liters
Frame	Steel perimeter
Engine Type	Single-cylinder, 4-stroke
