8.2 Rundown report
RUNDOWN REPORT 1(1)
Tool Identity Date Time
AB735 Jan 28 2008 09:33.12
COMMENT ROW 1
COMMENT ROW 2
Torque Angle No. of pulses
MAX 80 Nm 200 deg 15
MIN 70 Nm 150 5
MEAN 74.79 Nm 164.3 deg 9.333
MEAN - 3 SIGMA 61.72 Nm 136.4 deg 2.853
MEAN + 3 SIGMA 87.86 Nm 192.2 deg 15.81
SIGMA/MEAN 0.058 0.057 0.231
Range 19.3 30 8
Range % 38.6 9 80
CMK 0.55 5.00 34.00 FAILED
Number Torque Angle Pulses Status Date Time
Nm) deg)
15 71.00 166.0 8 OK/OK/OK Jan 28 2008 09:33.12
14 72.20 167.0 7 OK/OK/OK Jan 28 2008 09:29.45
13 70.40 166.0 9 OK/OK/OK Jan 28 2008 09:24.53
12 76.10 169.0 10 OK/OK/OK Jan 28 2008 09:20.45
11 85.40 168.0 11 HIGH/OK/OK Jan 28 2008 09:19.12
10 74.20 159.0 12 OK/OK/OK Jan 28 2008 09:17.16
9 74.00 160.0 9 OK/OK/OK Jan 28 2008 09:15.51
8 66.10 141.0 4 LOW/LOW/LOW Jan 28 2008 09:14.25
7 73.20 160.0 12 OK/OK/OK Jan 28 2008 09:12.12
6 79.30 166.0 12 OK/OK/OK Jan 28 2008 09:10.12
5 75.30 165.0 11 OK/OK/OK Jan 27 2008 11:31.42
4 77.50 168.0 9 OK/OK/OK Jan 27 2008 11:15.32
3 75.10 169.0 9 OK/OK/OK Jan 27 2008 10:59.33
2 76.70 155.0 8 OK/OK/OK Jan 27 2008 10:57.41
1 75.40 185.0 9 OK/OK/OK Jan 27 2008 10:55.11
TOOL COMMENT Replace cable
TEST PERFORMED BY: AJN
APPROVED BY
