Atlas Copco ACTA 4000 User Manual

Technical specifications ACTA 4000 User Guide
124 (136) 2008-12 9836 4171 01
Pin Description Pin Description
B Excitation, -5VDC M Gyro signal
C + Signal N Gnd
D - Signal P Gnd Angle encoder & transducer memory
E Shield R +5VDC to angle encoder
F Angle encoder CW trail S Yellow LEDs
G Clock signal for transducer memory T +8V To transducer memory
H Angle encoder CW lead U Green LEDs
J Data signal for transducer memory V Red LEDs
K +12V
10.1.2 Barcode Reader
A Barcode Reader (BCD) is used to select tools in the database or set the sequence number. A tool
message from the BCD equivalent to a Tool ID in the database, ACTA selects that tool.
Message layout Tool ID:
A sequence number message from the BCD sets the sequence number to the code starting in position
Barcode position with the length Barcode length. The Barcode position and Barcode length are
configuration parameters. Use the
Configuration menu to set these parameters.
Message layout sequence number:
STX Sequence no. ETX
Barcode reader setup
Parameter Value
Baud rate 9600
Parity None
# of stop bits 1
# of data bits 8
Flow control None
Stop character STX .... ETX
ACK / NAK On
Xon/Xoff Off
RTS/CTS Off
STX ? ? Tool ID ETX
