ACTA 4000 User Guide Technical specifications
9836 4171 01 2008-12 125 (136)
10.2 Default Setups
10.2.1 ACTA
Item Set-up
Torque unit Nm
Pulse unit Number of
Language English
Backlight On
Buzzer Off
Date/time Current
Routing Off
New sequence no. Off
Printer protocol PCL3 (only ACTA 3000)
Paper size A4 (only ACTA 3000)
Color Off (only ACTA 3000)
Baud rate 115200 (not possible to change)
Flow control Hardware
User ----
Torque value Four digits
Bar-code position 1
Bar-code length 8
Ethernet DHCP
10.2.2 Q-prog
This setup is obtained when carrying out quick programming choosing direct driven, pulse, wrench or
click wrench.
Direct driven Pulse Wrench Click Wrench
Target torque
0.75 * TCT * TTS 0.75 * TCT * TTS 0.75 * TCT * TTS 0.75 * TCT * TTS
Calibration torque
0.75 * TCT * TTS 0.75 * TCT * TTS 0.75 * TCT * TTS 0.75 * TCT * TTS
Parameter set
0 0 0 0
Controller
None None None None
Communication
Manual input Manual input Manual input Manual input
Cell ID
0 0 0 0
Channel
1 1 1 1
Model
Tensor S Tensor S Tensor S Tensor S
Filter frequency
500 Hz 1500 Hz 125 Hz 1000 Hz
