ACTA 4000 User Guide Printouts from ACTA
9836 4171 01 2008-12 103 (136)
8.4 Tool Setup
TOOL SETUP 1(1)
Tool identity Date Time
AB735 Jun 28 2008 10:55.12
APPLICATION NAME Rearview mirror
PARAMETER SET NAME 2
ZONE NAME B21
TARGET TORQUE 75.00 Nm
TARGET ANGLE 234 deg
CALIBRATION TORQUE 75.00 Nm
CONTROLLER PF3000/PF4000
COMMUNICATION RS232
PARAMETER SET 0
CELL ID 0
CHANNEL 0
MODEL Tensor S/ST
FILTER FREQUENCY 500 Hz
DIRECTION OF ROTATION CW
MEASURE STRATEGY Peak
CYCLE START 15.00 Nm
CYCLE COMPLETE 8.000 Nm
START ANGLE 10.00 Nm
MEASURE ANGLE TO Peak torque
MEASURE DELAY TIME 0 ms
RESET TIME 10 ms
END TIME 500 ms
Torque Angle No. of pulses
MIN 70.00 Nm 100.0 deg 30
MAX 80.00 Nm 150.0 deg 35
LCLx 73.00 Nm 0.0 deg
UCLx 77.00 Nm 9999 deg
LCLr 0.000 Nm 0.0 deg
UCLr 5.000 Nm 9999 deg
CM > 80.00 0.000
CMK > 1.330 0.000
CAM > 2.000 0.000
MEAN DIFFERENCE< 6.000 % 10.00 %
BATCH SIZE 5
SUBGROUP SIZE 5
SUBGROUP FREQUENCY 0
BATCH RESULT On
MEASURED PARAMETER 1 Torque
MEASURED PARAMETER 2 Angle
STATISTIC PARAMETER 1 X, S
STATISTIC PARAMETER 2 None, None
TORQUE UNIT Nm
PULSES UNIT Number of
To Next Page
