ACTA 4000 User Guide Programming ACTA
9836 4171 01 2008-12 51 (136)
To exit use the OK button or use the arrow keys to highlight OK field and press ENTER. The parameter
values will be saved in the selected position.
The transducer database is saved in non-volatile memory and the information is kept
intact during power off.
ACTA 4000 handles amplified transducers by shutting off the internal amplifier.
ACTA 3000 can NOT handle amplified transducers.
4.5.4 Transducer memory
This section is mainly for Atlas Copco service personnel.
The transducer memory information is shown in two dialog boxes. To change between the two dialog
boxes use the right and left arrow soft keys. They are displaying the data received from an Atlas Copco
memory transducer if such is connected to ACTA.
This information is not identical in ACTA 3000 and ACTA 4000.
The information displayed is calculated on all tightening operations in the tool.
Transducer memory 1
Type
Type of transducer
Serial number
Sensitivity
Calibration torque
Torque span
Expressed in % of Calibration torque
Angle encoder
Yes or No
No. of measurements
Number of tightening operations
Transducer memory 2
Calibration date
Calibration source
Next cal.date
Last update
Signature
Comment
Transducer memory 1 Transducer memory 2
