ACTA 4000 User Guide Programming ACTA
9836 4171 01 2008-12 47 (136)
2 TTQAT
Settings for communication with ToolsTalk QAT.
1. TTQAT media
The communication interface; RS232, USB, or Ethernet.
2. Client port
The port to which ACTA is listening for incoming Ethernet.
3. Server hostname
Host name for TTQAT server
4. Server IP address
TTQAT server IP address. Only used if ACTA must contact
a specific server with a message that it is connected.
5. Server port
The port ACTA is using to contact the TTQAT server.
3 Barcode
Settings for communication with a barcode reader.
1. Barcode media
The communication interface; RS232, USB, or Ethernet.
2. Barcode position
Position in the barcode where reading should start.
3. Barcode length
Length of reading in barcode, starting from barcode position.
4.5.2 Calibration
From this pull-up menu calibrations are executed. The following calibrations are available:
1 ACTA
Calibration of ACTA. See section Calibrating tools and equipment for
details.
Only authorized service personnel. Contact Atlas Copco.
2 Deadweight
Calibration with deadweight equipment. See section Calibrating tools
and equipment for details
3 Tool
Calibration of tool. See section Calibrating tools and equipment for
details
4.5.3 Diagnostics
This pull-up menu gives access to diagnostic windows. It also contains dialog boxes for continuous
measurement and shunt calibration.
1 Transducer
This opens the Transducer diagnostics windows. It is a double window
information dialog. The ← and → soft keys toggle between the
windows.
Only authorized service personnel. Contact Atlas Copco.
2 Battery
Opens the battery information window displaying information on
battery status and shows whether the main current is connected.
