ACTA 4000 User Guide Programming ACTA
9836 4171 01 2008-12 39 (136)
4.4.4 Manual Input
This function allows you to enter manual measurement values, including Torque, Angle and Pulses, in to
your ACTA.
This is useful where it may be difficult to access an application on the line with a transducer connected to
ACTA. You can therefore record the measurements with a digital torque wrench and then enter them
manually in ACTA.
The measurements will be regarded as real measurements by your ACTA but in ToolsTalk QAT it will be
noted that the measurements are manually entered.
Menu item Description
1 Tightening
The tightening input window lets you manually enter tightening
values.
Torque must be specified. Angle and Pulses can be specified.
2 Tool comment
This opens the Enter tool comment field for you to enter a comment
concerning a tool. For example, if the tool is moved from position or
damaged. This information creates a comment in ToolsTalk QAT
where it can be handled further.
3 Controllers
The controller input window lets you specify controller torque and
controller angle for the last tightening operation in the
C-torque and
C-angle fields. The old controller value is displayed in the input field.
4 Sequence no
This opens the Enter sequence number field letting you specify next
sequence number.
