ACTA 4000 User Guide Technical specifications
9836 4171 01 2008-12 127 (136)
Direct driven Pulse Wrench Click Wrench
Statistical parameter 1
Mean, σ Mean, σ Mean, σ Mean, σ
Torque units
Torque units set by
Config.
Torque units set by
Config.
Torque units set by
Config.
Torque units set by
Config.
Pulse units
Pulse units set by
Config.
Pulse units set by
Config.
Pulse units set by
Config.
Pulse units set by
Config.
Parameter 2
None (If transducer
has an angle encoder:
Angle)
No. of pulses None (If transducer
has an angle
encoder: Angle)
None (If transducer
has an angle
encoder: Angle)
Statistical parameter 2
None (If transducer
has an angle encoder:
Mean, σ)
Mean, σ
None (If transducer
has an angle
encoder: Mean, σ)
None (If transducer
has an angle
encoder: Mean, σ)
Comments row 1
Comments row 2
TCT = Transducer Calibration Torque
TTS = Transducer Torque Span
10.2.3 Synchronize
These setups is available in Q-prog synchronize. F2000/PF2000 is only available in ACTA 3000.
Q.prog selection No controller Other
controller
F2000/PF2000
Manual input
F2000/PF2000
RS232
DS/DL
Manual input
Target torque
Depending on
selections
0.75 * TCT *
TTS
0.75 * TCT * TTS Read from controller 0.75 * TCT *
TTS
Calibration torque
0.75 * TCT *
TTS
Depending on
selections
0.75 * TCT * TTS Read from controller 0.75 * TCT *
TTS
Parameter set
0 0 0 Read from controller 0
Controller
None Other controller F2000/PF2000 F2000/PF2000 DS/DL
Communication
Manual input Manual input Manual input RS232 Manual input
Cell ID
0 0 0 Depending on
selections
0
Channel
1 1 1 1 1
Model
None None Tensor S Tensor S Tensor S
Filter frequency
Depending on
selections
Depending on
selections
500 Hz 500 Hz 500 Hz
Rotation direction
CW CW CW CW CW
Measure strategy
Depending on
selections
Peak Peak Peak Peak
Cycle start
0.05 * TCT 0.05 * TCT 0.05 * TCT Read from controller 0.05 * TCT
Cycle complete
0.10 * TCT 0.10 * TCT 0.10 * TCT Read from controller 0.10 * TCT
Start angle
0.12 * TCT 0.12 * TCT 0.12 * TCT Read from controller 0.12 * TCT
Angle complete
Peak torque Peak torque Peak torque Read from controller Peak torque
