Programming ACTA ACTA 4000 User Guide
54 (136) 2008-12 9836 4171 01
4.6 Database (Datab)
Under the Datab menu block, the Quality Control and Advanced Analysis versions feature a tool database
where you can organize tools as well as measurement data for each tool.
4.6.1 New tool
This function creates a new tool in the database. ACTA copies all settings of the current tool to the new
tool you have created and then automatically selects and displays the new tool. Note how the tool ID on
the top border of the display has changed to the new tool ID. All measurements made now will be linked
to the new tool.
4.6.2 Select Tool
This function is used to select which tool in ACTA database to perform tightening on. Scroll in the list
using the soft key arrows, or use the search engine situated above the list. Use the keypad to write the
sought after tool ID in the box, and ACTA continuously searches for the tool in the database. Tools
starting with the entered letters are highlighted.
Use the
ENTER key to validate your choice and ACTA returns to the measurement dialog box. Your tool
selection is confirmed by its tool ID now being displayed at the top in the frame of the measurement
dialog box. This tool will be the one you measure until you select another tool.
It is not possible to measure tightening operations with a backup tool. See section
Backup tool.
Datab
1 New tool
2 Select tool
3 Delete tool
4 Clear all measurements
5 Backup tool
6 Information
1 Selected tool
2 All tools
Basic, Quality Control &
Advanced Analysis
Quality Control &
Advanced Analysis only
Advanced Analysis only
