Measuring strategies ACTA 4000 User Guide
72 (136) 2008-12 9836 4171 01
Slip Torque
The negative step required to start measurement of the breakaway level.
Min. Torque
The minimum torque allowed for an accepted tightening operation on the
current application. Relates to the application, not the tool.
Max Torque
The maximum torque allowed for an accepted tightening on the current
application. Relates to the application, not the tool.
Min. Angle
The minimum angle allowed for an accepted tightening operation on the
current application. Relates to the application, not the tool.
Max. Angle
The maximum angle allowed for an accepted tightening operation on the
current application. Relates to the application, not the tool.
Angle complete
Angle complete
selection selects the criteria for measuring the final angle.
Min. no. of Pulses
The minimum number of pulses allowed for an accepted tightening
operation on the current application. Relates to the application, not the tool.
Max. no. of Pulses
The maximum number of pulses allowed for an accepted tightening
operation on the current application. Relates to the application, not the tool.
5.2 Available measuring strategies
To open the measuring strategies dialog box, do the following:
1. Select
Prog>Measurement setup>Measure strat.
2. Select a measuring strategy. For more information, see the following sections.
The curves displayed below do not fully represent actual tightening curves. Their
shapes are relevant only to illustrate the Program measurement parameters
The point where the angle is measured can be set to peak torque, max angle or cycle
complete. This is valid for all measure strategies.
The parameters in the figures in this chapter are explained closer in Measure strategy
paramete
rs.
