3. Click the Add button; the Add Record dialog box appears:
Figure 11-9: Add Record Dialog Box for NFS
4. Configure the NFS parameters according to the table below.
5. Click the Submit button; the remote NFS file system is immediately applied, which
can be verified by the appearance of the 'NFS mount was successful' message in the
Syslog server.
6. To save the changes to flash memory, see 'Saving Configuration' on page 324.
Notes:
• To avoid terminating current calls, a row must not be deleted or modified
while the device is currently accessing files on that remote NFS file
system.
• The combination of 'Host Or IP' and 'Root Path' must be unique for each
row in the table. For example, the table must include only one row with a
Host/IP of 192.168.1.1 and Root Path of /audio.
• The NFS table can also be configured using the table ini file parameter
NFSServers (see 'NFS Parameters' on page 468)
Table 11-16: NFS Settings Parameters
Parameter Description
Index The row index of the remote file system.
The valid range is 1 to 16.
Host Or IP
[NFSServers_HostOrIP]
provided, a DNS server must be configured.
Root Path
[NFSServers_RootPath]
Path to the root of the remote file system in the format: /[path]. For
example, '/audio'.
NFS Version
[NFSServers_NfsVersion]
NFS version used to access the remote file system.
 [2] NFS Version 2
 [3] NFS Version 3 (default)
