AudioCodes MediaPack Series MP-11x User Manual

User's Manual 412 Document #: LTRT-65417
MP-11x & MP-124
Keyword Sub Types Attributes
Param Param Read/Write
Below are header manipulation examples:

Add parameter "itsp-abc=voip" to the Event header as follows:
Event: foo;id=1234;itsp-abc=voip
Message Type Condition Action Subject
Action
Type
Action Value
invite header.event.param.itsp-
abc
Add 'voip'

Modify the Event ID string as follows:
Event: foo;id=5678
Message Type Condition Action Subject
Action
Type
Action Value
invite header.event.EVENTKEY.id Modify '5678'

Modify the Event package enum as follows:
Event: refer;id=5678
Message
Type
Condition Action Subject
Action
Type
Action Value
invite header.event.EVENTKEY.EVENTPACKAGE Modify '2'
42.2.9 Expires
An example of the header is shown below:
Expires: 200
The header properties are shown in the table below:
Header Level Action Add Delete Modify List Entries
Operations Supported Yes Yes Yes NA
Keyword Sub Types Attributes
expires int Read/Write
Below is a header manipulation example that changes the value in the Expires header to
"500" (for all messages) as follows:
Expires: 500
Message Type Condition Action Subject
Action
Type
Action Value
header.expires.time Modify '500'

AudioCodes MediaPack Series MP-11x Specifications

General

Type	Analog VoIP Gateway
Category	Gateway
Network Interface	10/100 Mbps Ethernet
Ethernet Ports	1
Fax Support	T.38, G.711 pass-through
Relative Humidity	10% to 90% non-condensing
Product Series	MediaPack
Model	MP-11x
Ports	4 or 8 FXS ports
FXS Ports	4 (MP-114), 8 (MP-118)
Voice Codecs	G.711, G.723.1, G.726, G.729
Protocols	SIP, H.323, MGCP
Management	Web-based, Telnet, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
