13.6 Configuring DSP Templates
The DSP Template determines the coders that can be used by the device and various
other functionalities. For a list of DSP templates and the maximum number of channels
supported by each coder, see 'DSP Templates' on page 617. You can select a single DSP
Template.
Notes:
• If no entries are defined, the device uses the default DSP template (i.e.,
Template 0).
• A single DSP Template can also be configured using the ini file
parameter, DSPVersionTemplateNumber.
 To select a DSP Template(s):
1. Open the General Settings page (Configuration tab > VoIP menu > Media > General
Media Settings).
Figure 13-10: Defining Single DSP Template in General Settings Page
2. In the 'DSP Version Template Number' field, enter the required DSP Template
number.
3. Click Submit.
4. Reset the device with a flash burn for the settings to take effect (see 'Saving
Configuration' on page 324).
