 To configure the Charge Codes:
1. Open the Charge Codes Table page (Configuration tab > VoIP menu > GW and IP
to IP submenu > Analog Gateway submenu > Charge Codes). Alternatively, you can
access this page from the Metering Tones page (see 'Configuring Metering Tones' on
page 262).
Figure 25-3: Charge Codes Table Page
2. Configured the charge codes, as required. For a description of the parameters, see
the table below.
3. Click Submit to apply your changes.
4. To save the changes to the flash memory, see 'Saving Configuration' on page 324.
Table 25-1: Charge Codes Table Parameter Description
Parameter Description
End Time
[ChargeCode_EndTime<1-4>]
Defines the end of the time period in a 24 hour format, hh. For
example, "04" denotes 4 A.M.
Notes:
 The first time period always starts at midnight (00).
 It is mandatory that the last time period of each rule end at
midnight (00). This prevents undefined time frames in a
day.
Pulse Interval
[ChargeCode_PulseInterval<1-4>]
Defines the time interval between pulses (in tenths of a
second).
Pulses On Answer
[ChargeCode_PulsesOnAnswer<1-
4>]
Defines the number of pulses sent on answer.
25.4 Configuring FXO Settings
The FXO Settings page allows you to configure the device's specific FXO parameters. For
a description of these parameters, see 'Configuration Parameters Reference' on page 461.
Note: The FXO Settings page is available only for FXO interfaces.
