AudioCodes MediaPack Series MP-11x User Manual

Version 6.6 373 MP-11x & MP-124
User's Manual 36. Reporting Information to External Party
Below is an example of RADIUS Accounting, where the non-standard parameters are
preceded with brackets:
Accounting-Request (361)
user-name = 111
acct-session-id = 1
nas-ip-address = 212.179.22.213
nas-port-type = 0
acct-status-type = 2
acct-input-octets = 4841
acct-output-octets = 8800
acct-session-time = 1
acct-input-packets = 122
acct-output-packets = 220
called-station-id = 201
calling-station-id = 202
// Accounting non-standard parameters:
(4923 33) h323-gw-id =
(4923 23) h323-remote-address = 212.179.22.214
(4923 1) h323-ivr-out = h323-incoming-conf-id:02102944 600a1899
3fd61009 0e2f3cc5
(4923 30) h323-disconnect-cause = 22 (0x16)
(4923 27) h323-call-type = VOIP
(4923 26) h323-call-origin = Originate
(4923 24) h323-conf-id = 02102944 600a1899 3fd61009 0e2f3cc5
36.3 Event Notification using X-Detect Header
The device supports the sending of notifications to a remote party notifying the occurrence
(or detection) of certain events on the media stream. Event detection and notifications is
performed using the SIP X-Detect message header and only when establishing a SIP
dialog.
For supporting some events, certain device configurations need to be performed. The table
below lists the supported event types (and subtypes) and the corresponding device
configurations, if required:
Table 36-4: Supported X-Detect Event Types
Events Type Subtype Required Configuration
CPT SIT-NC
SIT-IC
SIT-VC
SIT-RO
Busy
Reorder
Ringtone
SITDetectorEnable = 1
UserDefinedToneDetectorEnable = 1
Note: Ensure that the CPT file is configured with the
required tone type.
FAX CED (IsFaxUsed ≠ 0) or (IsFaxUsed = 0, and
FaxTransportMode ≠ 0)
modem VxxModemTransportType = 3
PTT voice-start
voice-end
EnableDSPIPMDetectors = 1
