3-39

Confidential

9.9 Side cover R

(1) Remove the two taptite bind B M4x12 screws. Release the hook A, B and C of the arrow

A to C in this order, and remove the side cover R.

Fig. 3-29

Side cover R

Hooks B

Hooks C

Hooks A

Taptite bind B M4x12

Taptite bind

B M4x12
