2. PERIODICAL REPLACEMENT PARTS

2.1 Preparation

 Disconnecting Cables and removing Accessories

Prior to proceeding with the disassembly procedure,

(1) Disconnect the following:

•AC cord

• USB cable (if connected)

• LAN cable (if connected)

• Line cord (if connected)

(2) Remove the following:

• Paper tray

• Toner cartridge and Drum unit

• Duplex tray

• LAN port cap

Fig. 7-1

Paper tray

Toner cartridge and Drum unit

Duplex tray

AC cord

LAN port cap

LAN cable

USB cable

Line cord
