Brother MFC-8535DN Service Manual

5-53
Confidential
1.3.28 Display machine log information (function code: 80)
<Function>
This function is used to display the log information on the LCD.
<Operating Procedure>
(1) Press the [8], and then the [0] key in the initial state of maintenance mode.
"MACERR_01:****" is displayed on the LCD (**** indicates error code).
(2) Pressing the [▲] or [▼] key changes the display item.
(3) Press the [X] key, and the machine returns to the initial state of maintenance mode.
Maintenance information
LCD Description
MACERR_##:0000
Machine error log (last ten errors)
*1
USB:000G8J000166
Serial number
*2
MAC:008077112233 MAC address
PCB:911309123456 Main PCB serial number
KTN_ERM:87%
Estimated remaining toner amount based on the average coverage
KTN_RRM:67% Estimated remaining toner amount based on the rotations of
develop roller
DRUM_PG:00000000 Printed pages for drum unit
PFMP_PG:00000000 Pages fed from PF kit MP
PFK1_PG:00000000 Pages fed from PF kit 1
PFK2_PG:00000000 Pages fed from PF kit 2
PFK3_PG:00000000 Pages fed from PF kit 3
PFK4_PG:00000000 Pages fed from PF kit 4
PFK5_PG:00000000 Pages fed from PF kit 5
FUSR_PG:00000000 Printed pages for fuser unit
LASR_PG:00000000 Printed pages for laser unit
TTL_PG:00000000 Total number of pages printed
DX_PG:00000000 Paper input for duplex tray
TTLCOPY:00000000
Total pages copied
DX_COPY:00000000
Total pages copied on both sides
TTLPCPT:00000000 Total pages printed via PC
DX_PCPT:00000000
Total two-sided pages printed via PC
TTLFAX:00000000
Total List / Fax pages printed
*3
DX_FAX:00000000
Total List / Fax pages printed on both sides
*3
TTL_OTH:00000000 Total pages printed by other methods
DX_OTH:00000000 Total two-sided pages printed by other methods
