Brother MFC-8535DN Service Manual

5-25
Confidential
 Adjust left-end print position
<Function>
In the event that the left-end print start position deviates, use this function to adjust the
position left and right. The adjustable range is -100 to 750 (unit: 300 dpi). (Shifted to the left
when the value is negative)
<Operating Procedure>
(1) Press the [4], and then the [5] key in the initial state of maintenance mode. "USBNo." is
displayed on the LCD.
(2) Press the [▲] or [▼] key to display "X Adjust" on the LCD, and press the [Mono Start] or
[SET] key. "XAdjust MP" is displayed on the LCD.
(3) Refer to <Adjustment option table> below, press the [▲] or [▼] key to select from the
adjustment options, and press the [Mono Start] or [SET] key. "XAdj. **= 0*" is displayed
on the LCD. (Selected option is shown for **.)
(4) To shift the writing start position to the left, press the [▼] key to decrease the value. To
shift the position to the right, press the [▲] key to increase the value.
(5) Press the [Mono Start] or [SET] key after adjusting the value. "Accepted" is displayed on
the LCD, and the machine returns to the initial state of maintenance mode.
(6) Press the [X] key to return the machine to the initial state of maintenance mode.
<Adjustment option table>
"X" or "Y" is shown for *.
Adjustment option LCD Adjustment option LCD
MP tray first side *Adjust MP MP tray second side *Adjust DXMP
Paper tray 1 first side *Adjust T1 Paper tray 1 second side *Adjust DXT1
Paper tray 2 first side *Adjust T2 Paper tray 2 second side *Adjust DXT2
Paper tray 3 first side *Adjust T3 Paper tray 3 second side *Adjust DXT3
Paper tray 4 first side *Adjust T4 Paper tray 4 second side *Adjust DXT4
Paper tray 5 first side *Adjust T5 Paper tray 5 second side *Adjust DXT5
Duplex tray *Adjust DX
