2-9
Confidential
Part name Operation
MP separation roller,
MP separation pad
Separates the paper fed from the MP tray into single sheets in
the MP separation roller.
MP paper empty actuator
(MP paper empty sensor)
Detects the paper in the MP tray.
Detects paper jams in the MP tray.
Eject stack actuator
(Eject stack sensor)
Detects the full of a machine output tray.
(Models with USB host on the rear side only.)
Document pick-up roller Feeds document from the document tray.
Document separate roller,
ADF separation pad
Separates the document fed from the document tray into single
sheets.
Document detection actuator
(Document detection
sensor)
Detects whether a document is set in the ADF.
Document scanning position
actuator
(Document scanning
position sensor)
Detects the document scanning start position.
Detects a document jam in the ADF.
Document eject roller Feeds the document to the output tray.
ADF cover sensor Detects open / closed ADF cover.
