3. Pull the tab gently in a slightly downward direction until it disengages from the port, then pull the SFP
module out as shown in the following figure.
Figure 53: Removing a Mylar Tab SFP Module
4. Place the removed SFP module on an antistatic mat, or immediately place it in a static shielding bag if
you plan to return it to the factory.
5. Protect your line card by inserting clean SFP module cage covers into the optical module cage when there
is no SFP module installed.
When pulling the tab to remove the SFP module, be sure to pull in a straight outward motion so you remove
the SFP module from the port in a parallel direction. Do not twist or pull the tab, because you might disconnect
it from the SFP module.
Note
Actuator Button SFP or SFP+ Module
The actuator button SFP or SFP+ module includes a button that you push to remove the SFP module from a
port as shown in the following figure.
Figure 54: Actuator Button SFP or SFP+ Module
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
101
Installing and Removing Line Cards and Transceiver Modules
Actuator Button SFP or SFP+ Module
