Cisco A9K-MOD400-TR User Manual

2-Port 40-Gigabit Ethernet Modular Port Adapter with QSFP+
The 2-Port 40-Gigabit Ethernet (GE) modular port adapter (MPA) provides two cages for QSFP+ Ethernet
optical interface modules that operate at a rate of 40 Gbps. The two QSFP+ modules can be 40-Gigabit Ethernet
multimode or single mode connections.
Each QSFP cage on the MPA has an adjacent A/L (Active/Link) LED visible on the front panel. The A/L
LED indicates the status of the associated QSFP port as described in 2-Port 40-Gigabit Ethernet MPA LEDs
table below, and a Status LED for the MPA as shown in the following figure.
Note: This MPA is not compatible with consumption-model MOD400 line card.
Note
Figure 31: 2-Port 40-Gigabit Ethernet Modular Port Adapter
Status
LED
2A/L (Active/Link) LED1
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
62
Overview
2-Port 40-Gigabit Ethernet Modular Port Adapter with QSFP+

Cisco A9K-MOD400-TR Specifications

General

Brand	Cisco
Model	A9K-MOD400-TR
Category	Network Router
Language	English
