Table 18: 2-Port 10-Gigabit Ethernet MPA LEDs
MeaningStateColorLED
Label
Port is not enabled.OffOffA/L
Port is enabled and the link is up.
The MPA A/L (Active/Link) LED will blink green and amber when there is traffic activity.
OnGreen
Port is enabled and the link is down.OnRed
Modular port adapter power is off.OffOffSTATUS
Modular port adapter is ready and operational.OnGreen
Modular port adapter power is on and good, and the modular port adapter is being configured.OnAmber
4-Port 10-Gigabit Ethernet Modular Port Adapter with XFP
The 4-Port 10-Gigabit Ethernet (GE) modular port adapter (MPA) provides four cages for XFP Ethernet
optical interface modules that operate at a rate of 10 Gbps. The four XFP modules can be 10GE multimode
or single mode connections.
The MPA has two types of LEDs: an A/L (Active/Link) LED for each individual port and a Status LED for
the MPA as shown in the following figure. The A/L LED indicates the status of the associated XFP port, as
described in the below table 4-Port 10-Gigabit Ethernet MPA LEDs .
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
56
Overview
4-Port 10-Gigabit Ethernet Modular Port Adapter with XFP

Cisco A9K-MOD400-TR Specifications

General

Brand	Cisco
Model	A9K-MOD400-TR
Category	Network Router
Language	English
