Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into beams or
view directly with optical instruments. Statement 1051
Warning
Ultimate disposal of this product should be handled according to all national laws and regulations. Statement
1040
Warning
If you need to remove a CFP transceiver, follow these steps:
1. Disconnect the network fiber-optic cable from the CFP transceiver connectors. Immediately reinstall the
dust plugs in the CFP transceiver optical bores.
2. Loosen the two captive installation screws that secure the CFP to the networking module.
3. Slide the CFP transceiver out of the module socket (see the figure below). Immediately place the CFP
transceiver in antistatic protective packaging.
Figure 70: Removing a CFP Transceiver Module
Installing and Removing QSFP+/QSFP28 Transceiver Modules
This section provides the installation, cabling, and removal instructions for the 40-Gigabit Quad Small
Form-Factor Pluggable Plus (QSFP+) and 100 Gigabit (QSFP28) transceiver modules. The modules are
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
115
Installing and Removing Line Cards and Transceiver Modules
Installing and Removing QSFP+/QSFP28 Transceiver Modules
