StatusPort LED State
100G interface is in down state.Red
100G interface is in up state.Green
100G interface is up and carrying traffic.Blinking Green and Amber
Plugging a non-supported CPAK to a CFP2 adapter can damage the CFP2 adapter. Ensure that you read the
PID label on the CFP2 adapter carefully.
Caution
It is strongly recommended to wait for 60 seconds before successive insertion or removal of optics. Failure
in following this recommendation may affect the functionality of optics.
Caution
The metal surfaces of CPF2-DCO modules may exhibit high temperature and can be unsafe for handling with
bare hands. Hot surface warning label is provided on the faceplate of the MPA where the optical module is
inserted.
Caution
For more information about how to remove the CFP2-DCO module, see Safe Removal of CFP2-DCO Modules,
on page 87.
2-Port 100-Gigabit Ethernet Modular Port Adapter with CFP2
The 2-Port 100-Gigabit Ethernet (GE) modular port adapter (MPA) supports LAN/WAN/OTN mode and
provides two cages of coherent transceiver CFP2 modules that operate at a rate of 100 Gbps.
The 2-Port 100GE MPA is supported on both bay 0 and bay 1 of 400 Gigabit Modular Line Card
(A9K-MOD400-SE, A9K-MOD400-TR, A9K-MOD400-CM) and on bay 0 of the 200-Gigabit Line Card
(A9K-MOD200-SE, A9K-MOD200-TR).
This MPA supports 10X10 and 2X40 breakout configuration.
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
50
Overview
2-Port 100-Gigabit Ethernet Modular Port Adapter with CFP2
